Grindex Bravo-200 Slurry Pump

Grindex



Submersible slurry pumps for pumping fluids with abrasive solids.

All slurry applications don't require heavy duty pumps, and to meet this demand Grindex offer two smaller models, Bravo 200 and Bravo 300. They are intended for applications with lower demands on capability and wear resistance, and they are not equipped with agitator. For capacities below these, we recommend Grindex sludge pumps.

Also available in Explosion Proof version.

Pump type

Electrical submersible three-phase Slurry pump

Classification

IP 68

Max submersion

20 m/66 ft

Cable

20 m/66 ft SUBCAB This pump requires an external starter box

Discharge connection

Hose, BSP or NPT

Limitations

pH 5.5-14

Max liquid temp

40°C/104°F (70°C/158°F on request)

60 Hz Bravo 200
Discharge connection 4"
Rated power P2 [kW/hp] 5.6 / 7.5
Max. power consumption P1 [kW] 6.7
Shaft speed [rpm] 1740
Rated current at 230V 19 A
Rated current at 460V 9.6 A
Rated current at 575V 7.8 A
Solids passage [mm/inch] 50 / 2
Height [mm/inch] 760 / 30
Diameter [mm/inch] 460 / 18
Weight [kg/lbs] 157 / 346
