Grindex Bravo-800 Slurry Pump


Submersible slurry pumps for pumping fluids with abrasive solids.

The Bravo 800 is extremely wear-resistant thanks to the use of Hard-ironTM and the low shaft speed. Equipped with an agitator to enhance the 'up-stirring' capabilities it is a superior quality pump for all kinds of slurry applications.

Also available in Explosion Proof version.




Technical specificationsPump type

Electrical submersible slurry pump


IP 68

Max submersion

20 m/66 ft


20 m/66 ft SUBCAB This pump requires an external starter box

Discharge connection

Connection: Victaulic


Allowed pH range: 5.5 - 14

Max liquid temp

40°C/104°F (70°C/158°F on request)

60 Hz Bravo 800
Discharge connection 6"
Rated power P2 [kW/hp] 52 / 79,7
Max. power consumption P1 [kW] 56
Shaft speed [rpm] 1775
Rated current at 460V 80 A
Rated current at 575V 63 A
Solids passage with agitator [mm/inch] 36 / 1 2/5
Height [mm/inch] 1652 / 65
Diameter [mm/inch] 875 / 34½
Weight [kg/lbs] 613/ 1351
