Grindex Minette Drainage Pumps
The Minette pump is the next smallest model in the drainage range, but it shares all important features and benefits with the larger models, resulting in the lowest cost per cubic meter pumped. The drainage range of pumps drain water, not your wallet! The revolutionary hydraulic design ensures high wear resistence and dramatically reduces performance drop due to long time wear.
The Minette pump is available in two configurations;
Minette 1-phase and Minette 3-phase.
Pump type
Electrical submersible One-phase and Three-phase
Classification
IP 68
Max submersion
20 meters
Cable
20 meters, SUBCAB: 1-phase: 3G1.5mm2 3-phase: 4G1.5mm2
Discharge connection
Hose, ISO-G or NPT
Limitations
pH 5-8
Max liquid temp
40°C
60 Hz | 1-ph | 3-ph |
Discharge connection | 3" | 3" |
Rated power P2 [kW/HP] | 1.8 / 2.4 | 2.6 / 3.5 |
Max. power consumption P1 [kW] | 2.2 | 3.1 |
Shaft speed [r.p.m.] | 3405 | 3410 |
Rated current at 230V | 9.9 A | 9.5 A |
Rated current at 460V | - | 4.7 A |
Rated current at 575V | - | 3.5 A |
Solids passage [mm/inch] | 9 / 0.35 | 9 / 0.35 |
Height [mm/inch] | 676 / 26½ | 676 / 26½ |
Diameter [mm/inch] | 240 / 9½ | 240 / 9½ |
Weight [kg/lbs] | 29 / 64 | 29 / 64 |
