Grindex Minex MSHA

Grindex



The Minex pump is the smallest model in the drainage range, but it shares all important features and benefits with the larger models, resulting in the lowest cost per cubic meter pumped. The drainage range of pumps drain water, not your wallet! The revolutionary hydraulic design ensures high wear resistance and dramatically reduces performance drop due to long time wear.



Pump type

Electrical submersible One-phase and Three-phase

Classification

IP 68

Max submersion

20 m

Cable

20 m, SUBCAB: 1-ph: 3G1.5mm2 3-ph: 4G1.5mm2

Discharge connection

Hose, ISO-G or NPT

Limitations

pH 5-8

Max liquid temp

40°C

60 Hz 3-ph
Discharge connection 2"
Rated power P2 [hp/kW] 1.9 / 1.4
Max. power consumption P1 [kW] 1.8
Shaft speed [rpm] 3300
Rated current at 460V 2.6 A
Rated current at 575V 2.1 A
Solids passage [inch] 0.3
Hight [inch] 19.5
Diameter [inch] 10.1
Weight [lbs/kg] 47 / 21
