Grindex Salvador Inox Stainless Steel Pump
With its impressive allowed pH range, from 2 up to 10, it is hard to find an application that can't be handled by the Inox pumps. All materials in contact with the liquid are made out of AISI 316 stainless steel or better.
Pump type
Electrical submersible
Classification
IP 68
Max submersion
20m
Cable
H07RN8-F, length 20m 4x1.5 mm2 4x2.5 mm2
Discharge connection
Hose, BSP or NPT
Limitations
pH 2-10
Max liquid temp
40°C
60 Hz | Salvador Inox |
Discharge connection | 3" |
Rated power P2 [kW/hp] | 2.3 / 3.1 |
Max. power consumption P1 [kW] | 2.9 |
Shaft speed [rpm] | 3320 |
Rated current at 230V | 8.5 A |
Rated current at 460V | 4.2 A |
Rated current at 575V | 3.3 A |
Solids passage [mm/inch] | 50 / 2 |
Height [mm/inch] | 645 / 25½ |
Width [mm/inch] | 375 / 14¾ |
Weight [kg/lbs] | 47 / 104 |
