Grindex Sandy MSHA (Model N & H)

Grindex



Based on the same basic design as the drainage pumps, the sludge pumps come into action when the liquid gets dirtier than can be handled by the drainage pumps. The design even permits converting between drainage and sludge models allowing you to adapt the pump according to the varying conditions.



Pump type

Electrical submersible One-phase and Three-phase

Classification

IP 68

Max submersion

20 meters

Cable

SUBCAB

Discharge connection

Hose, ISO-G or NPT

Limitations

pH 5-8

Max liquid temp

40°C

60 Hz N H
Discharge connection 3" 3"
Rated power P2 [hp/kW] 8.9 / 6.6 8.9 / 6.6
Max. power consumption P1 [kW] 7.7 7.7
Shaft speed [rpm] 3500 3500
Rated current at 460V 11 A 11 A
Rated current at 575V 8.4 A 8.4 A
Solids passage [inch] 1.8 1.3
Hight [inch] 32.1 32.1
Diameter [inch] 18.3 18.3
Weight [lbs/kg] 127 / 58 127 / 58
