HCP Pumps IC Series (Submersible Dewatering Pump)
IC Series Features
The IC Series contains the following features:
- Standard design incorporating cable and dry motor, and equipped with thermal Auto-cut to prevent the motor from over heating. Abrasion resistant double mechanical seal and additional oil seal.
- Superior design of water cooled motor to ensure long life operation with high efficiency and energy savings.
- For above or below surface water applications, the IC strainer can be easily removed and replaced with a check valve, which allows for de-watering of underground water applications.
General Information
- Discharge Sizes 2–6”
- Hp Range 1.5–10
- Applications Dewatering
- Motor 2 Pole
- Solids Handling Size 1/4–1/2”
- Max Head 136 Ft.
- Max Flow 690 GPM
