HCP Pumps L Series (Large Volume Submersible Pump)

HCP Pumps America

L Series Features

The L Series contains the following features:

  • Large flow capacities achieved with almost no vibration by use of the axial and mix flow designs.
  • Robust construction and compact design with a dry motor, double mechanical seals, and impeller flow guide vane for high efficiency.
  • Easy-handling, energy-saving, and low maintenance.
  • Pump manufactured with heavy duty housing and double mechanical seals, and cable leads are isolated by hardened epoxy for water proofing
  • Casted ALBC3 (Aluminum Bronze) impeller with superior abrasion and corrosion resistance
  • High solids; epoxy coating prolongs metals from corroding and oxidizing.


General Information
  • Discharge Sizes 3–12”
  • Hp Range 1/2–20
  • Applications Dewatering
  • Motor 2 Pole (0.5–1Hp) or 4 Pole (2–20Hp)
  • Solids Handling Size 0.5–1.25”
  • Max Head 32 Ft.
  • Max Flow 2575 GPM
